64348 - EATON Ground Fuelling Configurator

Select: Hose End Control Valve

Hose End Control Valve

Hose End Control Valve with Flanged Inlet Connection

Flanged Hose End Control Valve (HECV)

Provides pressure limitation at the outlet to protect the aircraft while refueling.
Available with 15, 35, 45, 48, 50, 55, or 70 psi springs (1.034, 2.413, 3.103, 3.309, 3.447, 3.792, or 4.826 bar).

Add to compare

Product Name	Hose End Control Valve with Flanged Inlet Connection
Part Number	1
Short Description	Flanged Hose End Control Valve (HECV)
Description	Provides pressure limitation at the outlet to protect the aircraft while refueling. Available with 15, 35, 45, 48, 50, 55, or 70 psi springs (1.034, 2.413, 3.103, 3.309, 3.447, 3.792, or 4.826 bar).
Comment	Eaton's Carter^® brand hose end control valves (HECV) provide pressure limitation at the outlet to protect aircraft from over pressurization and surge while refueling. Pressure limitation - 5 psi (0.345 bar) over spring setting with inlet pressure up to 120 psi (8.274 bar) and 10 psi over spring setting at flow rates less than 5 gpm US (18.927 lpm). Downstream surge pressure generated, as a result of a rapid rise in downstream pressure (aircraft valve closure), is limited to 120 psi (8.274 bar) at 0.5 second aircraft valve closure. Designed in accordance with SAE AS 5877 and meets JIG industry standards.
Pressure	15, 35, 45, 48, 50, 55, or 70 psi springs (1.034, 2.413, 3.103, 3.309, 3.447, 3.792, or 4.826 bar).
Temperature	-35 F to +158 F
Product Sheet	Hose End Control Valves Brochure

Hose End Control Valve with Swivel Inlet Connection

Additional Info

Hose End Control Valve with Swivel Inlet Connection

Swivelled Hose End Control Valve (HECV)

Provides pressure limitation at the outlet to protect the aircraft while refueling.
Available with 15, 35, 45, 48, 50, 55, or 70 psi springs (1.034, 2.413, 3.103, 3.309, 3.447, 3.792, or 4.826 bar).

Add to compare

Product Name	Hose End Control Valve with Swivel Inlet Connection
Part Number	2
Short Description	Swivelled Hose End Control Valve (HECV)
Description	Provides pressure limitation at the outlet to protect the aircraft while refueling. Available with 15, 35, 45, 48, 50, 55, or 70 psi springs (1.034, 2.413, 3.103, 3.309, 3.447, 3.792, or 4.826 bar).
Comment	Eaton's Carter^® brand hose end control valves (HECV) provide pressure limitation at the outlet to protect aircraft from over pressurization and surge while refueling. Pressure limitation - 5 psi (0.345 bar) over spring setting with inlet pressure up to 120 psi (8.274 bar) and 10 psi over spring setting at flow rates less than 5 gpm US (18.927 lpm). Downstream surge pressure generated, as a result of a rapid rise in downstream pressure (aircraft valve closure), is limited to 120 psi (8.274 bar) at 0.5 second aircraft valve closure. Designed in accordance with SAE AS 5877 and meets JIG industry standards.
Pressure	15, 35, 45, 48, 50, 55, or 70 psi springs (1.034, 2.413, 3.103, 3.309, 3.447, 3.792, or 4.826 bar).
Temperature	-35 F to +158 F
Product Sheet	Hose End Control Valves Brochure

Without

Additional Info

Without

Without HECV

Add to compare

Product Name	Without
Short Description	Without HECV

5Second Hose End Control Valve

6Variable Inlet Elbow

7Inlet

8Options

9Handle

10Holder Bracket

11Order No.

Picture may differ from original product.

Part Number

64348...

Group	Eaton's Carter^® product line of ground fueling equipment includes several underwing refueling nozzle models.
Application	Underwing Refueling Nozzles for commercial usage.
Nozzle Type	Model 64348 - Lightweight and rugged Pressure Refueling Nozzle

Your choice:

Choose additional options or go on with:
